Goodeng GD320 LS Horizontal Directional Drilling Machine

Price 5910000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Goodeng GD320 LS Horizontal Directional Drilling Machine Specification

Condition
New

Product Type
Horizontal Directional Drilling Machine

Material
Mild Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
Normal

Power Source
Electric

Goodeng GD320 LS Horizontal Directional Drilling Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Goodeng GD320 LS Horizontal Directional Drilling Machine

The Goodeng GD320 LS Horizontal Directional Drilling Machine is a semi-automatic drilling machine that uses electric power as its source. It is made of high-quality mild steel material and is in a brand new condition. This drilling machine is not computerized and is perfect for those who prefer a more traditional approach. With its normal CNC feature, users can easily operate and control the machine manually. This drilling machine is perfect for drilling horizontal holes in a variety of materials, including soil, rocks, and concrete. With its durable design, it can withstand harsh environments and challenging working conditions.

Specifications

Rig weight	9700/10200kg	Dimension(LWH)	730021502250mm
Max thrust & pullback force	350/700KN	Max thrust & pullback speed	40m/min
Max torque	12600Nm	Max rotation speed	140r/min
Engine power	153kW	Max mud pump flow	320L/min
Caterpillar crawling speed	3.5-6km/h	Max mud pump pressure	8MPa
Entry drill angle	12-22	Max climbing gradient	18
Max back-reaming diameter	1100mm (soil dependent)	Max crossing length	400m (soil dependent)
